| 1. Power supply: AC220V, 50Hz; |
| 2. Movement range of the cross arm (radius): 750mm (can be configured according to the requirements of the hospital) |
| 3. Horizontal rotation angle: 0～340°, the cross arm and terminal box can rotate horizontally separately or at the same time; |
| 4. Net load weight ≥120kg; |
| 5. Instrument platform: 3 floors; adjustable height, rounded corners, anti-collision design, aluminum alloy plate, international standard side rail enclosure, |
| 6. Gas interface configuration: 4 oxygen, 4 negative pressure suction, 4 air; a. The color and shape of the interface are different, and it has the function of preventing wrong connection; b. The number of insertion and removal is more than 20,000 times; c. The use of secondary sealing, with three states (on, off, and unplug), can be repaired with air; |
| 7. Power socket: 12, 220V, 10A |
| 8. Equipotential grounding terminal: 1 |
| 9. Stainless steel adjustable infusion rod holder: 1 |
| 10. Internet phone interface: 1 |
| 11. Sundries basket: 1 |
| 12. The main material adopts high-strength aluminum alloy profiles; |
| 13. The surface treatment adopts electrostatic spraying; |
| 14. Ceiling installation, stable and firm. |
